SV 303 Class 1 Urban Noise Monitoring Terminal
The SV 303 is a Class 1 noise monitoring terminal for real-time urban and environmental sound assessment. It is designed for multipoint monitoring networks and can integrate with environmental systems or an SV 804 vibration monitor for synchronized noise and vibration data.
Key features
- Class 1 noise monitoring aligned with IEC 61672-1:2013 and IEC 61260-1:2014.
- Real-time environmental noise monitoring for urban and infrastructure applications.
- MEMS microphone with lifetime warranty according to Svantek product information.
- USB and UART interfaces for system integration.
- Optional 1/1 and 1/3-octave analysis and WAV audio-event recording.
- Optional connection to SV 804 through the SP 79 cable for synchronized four-channel noise and triaxial vibration monitoring.
- SvanNET support for remote access and data sharing.
Applications
- Environmental and community noise monitoring.
- Construction-site and infrastructure noise monitoring.
- Urban noise networks and smart-city monitoring.
- Combined noise and vibration monitoring with SV 804.
Specification summary
| Class | Class 1 |
|---|---|
| Standards | IEC 61672-1:2013 and IEC 61260-1:2014 |
| LAeq range | 30 dB to 130 dB, according to current Svantek product information |
| Interfaces | USB and UART |
| Optional analysis | 1/1-octave, 1/3-octave, and WAV audio-event recording |
| Integration | SV 804 via SP 79 cable; SvanNET platform support |
What it solves
The SV 303 provides a compact Class 1 terminal for distributed noise monitoring and can extend a structural-vibration deployment into a synchronized noise-and-vibration monitoring system.
Request a quotation for the Svantek instrument, local technical support, and calibration guidance from Absolute Instrument Sdn. Bhd.
